Impact Caement Windows

Product Specification

  •  Opening Style:  Casement
  •  Thermal Insulation:  U≤ 1.6W/㎡K
  •  Acoustic Performance:  ≤ 35 DB
  •  Air Tightness:  ≤ 0.4m³(㎡h)
  •  Wind Load Resistance:  ≥ 3.5 KPa
  •  Water Penetration:  ≥ 1500Pa
  •  Standard: Florida approved, Miami Dade approval
  •  Warranty: 10 Years
  •  Application: Residential, Commercial
  •  Performance: Hurricane Proof, Impact Resistance
  •  Main Markets: Florida, Caribbean Zone
Tech Specs

Technical Specs

hurricane-proof-window-section
  • Hi-Tech profile and reinforced material
  • Reinforced glass fiber thermal insulation bar with high loading capacity
  • Pressure extrusion for higher strength level
  • Coex wire seal to protect against moisture
  • Multi-point hardware lock system for weather sealing and burglarproofing
  • Truss structure design for increased structural strength
  • Tilt-turn system achieves the AAMA rating of CW-PG60
  • Corner locking key ensures the smooth surface joint and improves corner stability
  • Glass panel EPDM foam weather sealing strip used for better performance and easier maintenance than standard glue
Color

Color & Coating Options

Color & Coating Options
  • Superhouse Commen Color: Frosted Black, White Powder Coating
  • Silver grey powder coating, Silver anodising with INTERPON powder
  • Woodland grey(Satin), Ironstone(Stain), Shale Grey(Satin)
  • Ultra Silver(Gloss), Dune(Sain), Paperbark(Satin), Primrose(Gloss)
  • White Birch(Gloss), Surfmist(Matt), Architectural White(Satin)
  • Pearl White(Gloss), Silver Pearl Kinetic(Satin), Black(Satin)
  • Monument(Matt), Clear, Residential Bronze
  • Cedar, Mahogany, Honey Gum, Snow Gum
  • Select between factory-prefinished colors for fast delivery, or customized colors to better match your home
Glass

Glass Options

Glass Options
  • Single Glass(5mm, 6mm, 8mm, 10mm….)
  • Laminated Glass(5mm+0.76pvb+5mm)
  • Double Toughened Glass(5mm+12air+5mm)
  • Toughened Laminated Glass(5mm+12air+0.76pvb+5mm)
  • Triple Toughened Glass(5mm+12air+5mm+12air+5mm)
  • Thickness of single glass: 5-20mm
  • Glass types: Frosted glass, Toughened glass, Low-e coated glass
  • Special performance glass: Fireproof glass, Bulletproof glass
  • Select from various types of glass, including but not limited to: tinted, low-e, sound-proof and burglarproof
Screens

Screen Options

Screen Options
  • Screen Types: Stainless Steel Mesh, Fiberglass Screen, Retractable Screen
  • Fly and insect screen is a great way to keep insects out of your home
  • All fly screens are supplier with fibreglass mesh as standard
  • Midrail and handle hights depond on customer requirements
  • Fixed Screen is easy installation and removal
  • In-swing Screen can help you enjoy nature and keep the bugs out
  • Rolling Screen let you enjoy an unobstructed view when rulled up
  • The mesh screen is color coated together with the window to match perfectly.
  • Our screens are manufactured using aluminum alloy; strong enough to keep the mesh tight for years to come
Grille

Grille Options

Grille Options
  • Grilles between glass increase visual appeal and allows for easier glass cleaning
  • The grilles consist of a spacer bar placed between the panes of the insulating glass
  • It is available in the color that matches the exterior color of the window you choose
  • SDL Grilles are permanently attached to both the interior and exterior glass
  • Shadow bars that are placed between the two panes of insulating glass
  • Truss structure design for increased structural strength
  • Tilt-turn system achieves the AAMA rating of CW-PG60
  • Corner locking key ensures the smooth surface joint and improves corner stability
  • Glass panel EPDM foam weather sealing strip used for better performance and easier maintenance than standard glue

IMPACT CASEMENT WINDOW

The impact casement window is that the sash opening and closing is embedded in some horizontal directions. According to the opening method, the window can be divided into an inner opening, an outer opening, and an inner reversing.
The inner opening type of window cleaning is convenient; the outer opening type is widely used in various decoration places because of the large opening area of the casement window, good ventilation, good sealing performance, sound insulation, and excellent heat preservation performance.
For high-rise residents, in the face of typhoons, if window is not resistant to wind pressure, the impact is very large. In terms of airtight performance, the opening sector of the casement window is locked by a two-point lock or a heaven-and-earth lock.

Customize Your Windows

Florida Product Approval

Example Gallery

Impact Resistant Test
